134HD
2 Ply Poly 65 Black PVC AS FR
International designation: EM11/2 0/V6 AS FR
Construction:
Top Cover: Black PVC (0.60 mm) / 0.0236 in. — Smooth — Shore 70
Compound Bottom Cover: Polyester (0.00 mm) / 0.0000 in. — Bare — N/A
Number of Plies: 2
Anti-Static: Yes
Overall Gauge: 2.60 mm / 0.1024 in.
Unit Weight: 0.0597 lbs/PIW
Material Between Plies: PVC
Maximum Width: 84 in.
Temperature Range: High 180 °F, Low 20 °F
Pulley Diameter, Minimum:
Normal Flex: 1.7500 in. (44.45 mm)
Back Flex: 3.5000 in. (88.90 mm)
Belt Strength:
Pull for 1% Elongation: (11 N/mm) 65 lbs/sq. in.
Splice Instructions:
Foil: Yes
Splice Process: Finger
Press Temperature: 330 °F
Press Pressure: 25 lbs/sq. in.
Note: Listed above is a guideline only. Every vulcanizer is different and will show different results. We recommend that you do a test splice with your press before attempting the actual belt splice.
Other:
Cross Rigid: No
Impression Top: No
Oil Resistant: No
Fire Resistant: Yes
FDA Approved: No
