FYH UCPAN206PLBLKD11 30MM Adapter Sleeve Pillow Block with Polymer-fill Brg

UCPAN206PLBLKD11 - 30MM TB PB W/ POLYMER-FILL BRG

by FYH
$0.00 - $0.00
$0.00
$0.00
$0.00 - $0.00
$0.00

General

Product CategoryMounted Bearing
Ambient TemperatureHeat Resistant (-40 to 180 C) (-40 to 356 F)

Housing

Housing TypeTapped-Base Pillow Block
Housing SizePAN206
Housing MaterialBlack Thermoplastic
Bolt Centers2-19/32" - 66mm

Bearing Insert

Bearing Insert TypeUC
Bearing Insert Size206
Bearing Insert MaterialCarbon Steel
Bore Size - ID Diameter30MM
Bore TypeCylindrical
Locking SystemSet Screw

Request a quote

Housing type: Tapped-Base Pillow Block

Housing size: PAN206

Bolt Centers: 2-19/32" - 66mm

Housing Material: Black Thermoplastic

Bearing Insert Type: UC

Bearing Insert Material: Carbon Steel

Bore Size: 30MM

Bore Type: Cylindrical

Bearing Insert Size: 206

Locking system: Set Screw

Ambient Temperature: Heat Resistant (-40 to 180 C) (-40 to 356 F)

Seal Type:
