Shingle Polyflex conveyor belting is a solid extruded elastomeric resin. Polyflex Trackguard is manufactured in the USA by Shingle Belting, for use in automotive plants, and is available in OSHA Safety Yellow.
- Very cut & abrasion resistant
- 3mm thick
- Excellent impact resistance
- Resists flex fatigue
- Available from stock
- Made in the USA
- OSHA Safety Yellow
- Automotive Assembly
- Parts Assembly
- Assembly Paint Booths
To view these documents, you need Adobe Acrobat Reader. You can download a free copy from the Adobe web site.
| Belt Type | Thickness | Pull for 1% Elongation |
Minimum Pulley (Normal & Back Flex) |
Weight | Slab Size | Color | |||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| in | mm | lbs/in | N/mm | in | mm | lb/sq ft | kg/sq mtr | in | mm | ||
| Track Guard 3mm | 0.12 | 3.0 | 19 | 3.3 | 5 | 127 | 0.79 | 3.9 | 72"x200' | 1828 x 60960 | yellow |
| Belt Type | Thickness | Pull for 1% Elongation |
Minimum Pulley (Normal & Back Flex) |
Weight | Slab Size | Color | |||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| in | mm | lbs/in | N/mm | in | mm | lb/sq ft | kg/sq mtr | in | mm | ||
| Track Guard 3mm | 0.12 | 3.0 | 19 | 3.3 | 5 | 127 | 0.79 | 3.9 | 72"x200' | 1828 x 60960 | yellow |
